คุณสมบัติ / Specifications
Stroke: 160mm
Bore: 63mm
Action: Double
Manufacturer Series: PRA/802000/M
Length: 193.5mm
Pneumatic Connection: G 3/8
Piston Rod Thread Gender: Male
Cushioning Type: Air
Dimensions: 193.5 x 75 x 75mm
Width: 75mm
Absolute Maximum Pressure: 12bar
Maximum Operating Pressure: 12 bar
Height: 75mm
Test Weight: 1.54 kg @ 0 mm
VDMA Standard: 24562
ISO Standard: 15552
Minimum Operating Temperature: -20°C
Stroke Interval Weight: 0.13 kg @ 25 mm
Model Number p: PRA/802063/M/160
Maximum Operating Temperature: +80°C
Diameter: 63mm
